Technical detail. ------------------------------------ (7 Axis) The largest diameter: 50 mm Guide M48 From Mil to Center: Distance between 1170 and 2070 mm Circle diameter of drilled holes from 1370 to 2270 mm Shaft taper Morse 4 0-1585 mm Shaft taper Morse 5 0-1555 mm Spindle axis in a horizontal position between 295 and 2725 mm from the ground Vertical arm 1250 mm Horizontal adjustment 900 mm arms Swivel arm 360° Spindle Rotation 360° Tilting head with 180° of head runner bed travel with 1200 mm column Diameter of spindle head Morse taper 4 70 mm conical Morse 5 75 mm Spindle stroke (drilling depth) 350 mm Spindle speed - 15 degrees in the range of 16-800min-1 Shifts the spindle - 6 degrees in the range of 0.05 to 0.5 mm / revolution The biggest power slip is 10000N Spindle 4/1 425kW / 1/min Electric lift arms 2.2/1 420kW/1/min Electric slide for travel 1.1 / 1 420kW / 1 / min Electric motor for body compression 1.1 / 2 800kW / 1 / min Electric motor 1.1 / 2 800kW / 1 / min for tilting head and shoulder movements Bed dimensions: length x width x height 2610x1050x2600mm Largest backhoe dimensions: length x width x height 5740x4540x3440mm Machine weight 6100 kg.. It can be seen in Istanbul Customs..
